EMERGENCY REPORTING SYSTEMS
An easily installed receiver/interface for nurse station annunciators.
Emulates pull cord function via pendant wrist “panic
button” transmitter. Outputs activate annunciator windows, audible
alarms, room/corridor lights. Fail-safe operating mode.
 Now
you can add wireless emergency buttons to almost any nurse call system
with Linear's Pull Cord ALERTLINK
Reliable, efficient emergency reporting systems for
single or multiple users.
Features
- Interfaces to Most Nurse Call Systems.
- Adds Pendant Transmitter Capability.
- Emulates a Pull Cord Station.
- Fail-Safe Operating Mode.
- Trouble Contacts.
- Latching or Momentary Outputs.
- Accepts up to 32 DX Transmitters.
- All Linear DX transmitters are compatible with
the Pull Cord ALERT LINK receiver; however, Linear recommends use of
the ADDXT-21, ADDXT-61A, ADDXS-62, and the ADDXS-63.
- Compatible Modules
- Includes Power Supply.
|
Linear’s Pull Cord ALERTLINK adds pendant or wristband-style “panic
button” transmitter activation to most annunciator-based nurse call
systems.
This gives users freedom to move around, out of bed and away from the
pull cord, while retaining the ability to trigger a nurse call. Pull
Cord
ALERTLINK emulates a contact-type pull cord station used by many nurse
call systems. It includes outputs that can activate corridor lights,
room lights, annunciator lights, as well as audible alarms. While
designed for one to one usage, Pull Cord ALERTLINK can learn up to 32
Linear DX radio-based transmitters*.
Pull Cord ALERTLINK includes three indicator lights, as
well as a reset switch.The indicator lights
provide system status, including: POWER ON (green), SERVICE (yellow),
and ALERT (red).
The SERVICE indicator will illuminate whenever a transmitter sends a low
battery report to the receiver.The red ALERT indicator will light
whenever a transmitter is
activated.
The ALERT indicator will stay lit until the receiver mounted RESET
switch is activated for a minimum of three seconds.
The receiver has three inputs and five outputs.
The four alarm outputs latch upon activation of any recognized
transmitter and will remain latched until the RESET switch is activated
for a minimum of three seconds.
The unit can also be programmed Add wireless capability to any existing
nurse call station.
For momentary operation. In this configuration, the four alarm outputs
will transfer for a period of one second. Three of the outputs have a
common input and work in conjunction with each other while the fourth
output is completely isolated and is intended for system common
functions.
The relays operate in either the normal mode or a unique fail-safe mode.
In the normal mode, the relays operate only when a recognized
transmitter is activated. In the fail-safe mode, the relays operate both
upon activation of a recognized transmitter, as well as upon failure of
the Pull Cord ALERTLINK power source.
The fifth independent contact is used for low battery supervision of the
transmitters. Detection of a transmitter low battery will cause this
normally open contact to transfer its state.
Pull Cord ALERTLINK is powered from a supplied transformer.
It can be mounted directly to a wall or to a single-gang electrical box.
*When multiple devices are used, Pull Cord ALERTLINK cannot
identify the actual transmitter that was activated.
|
|
General Specifications
|
|
Operating Power: |
12 to 16 VAC or 12 to 16 VDC (note that a 16
VAC transformer is supplied with the unit) |
|
Operating Current: |
up to 120 mA |
|
Indicators: |
POWER ON (green); SERVICE (yellow);
transmitter low battery; and ALERT (red) transmitter alarm |
|
Radio Format: |
Linear DX |
|
Receiver Type: |
superheterodyne |
|
Operating Frequency: |
315 MHz |
|
Capacity: |
up to 32 transmitters |
|
Inputs: |
total of three - Alarm A, Alarm B,
Supervisory IN |
|
Outputs: |
total of five relay outputs rated at 1 amp at
120 VAC - Alarm Output A1, Alarm Output A2, Alarm Output A3,
Alarm Output B, Supervisory OUT |
|
Wiring Connections: |
color-coded wire leads |
|
Overall Size: |
5.25 inches H x 3.625 inches W x 1.5 inches D
(133 x 92 x 38 mm) |
|
Mounting: |
surface mount to wall or single-gang box |
|
Recommended Transmitters: |
DXT-21; DXT-61A; DXS-62; DXS-63 (note: all
Linear DX transmitters are compatible with the Pull Cord
ALERTLINK Receiver) |
|
|
|
